ELA2 viewed from the ELA3 launch pad. The ELA1 water tower is visible to the right.
The Ariane 4 assembly building, with V114's first stage visible.
ELA2 from the Ariane 4 assembly building, before gantry rollback.
ELA2 area after gantry rollback. The Ariane 4 assembly building is on the left of the picture and V113 and its launch tower are on the right. The building in the center is Arianespace's offices.
The ELA2 area after gantry rollback, with the V113 rocket visible at left center. The silver ELA1 water tower is just visible between the left hand gantry and the rocket, while the white ELA3 water tower is visible toward the right of the picture.
